Printer Maintenance (SATO CL4NX)

Maintenance Schedule

Perform routine maintenance at regular intervals and when replacing media or consumables.

Maintenance activities include:

• Cleaning

• Calibration

• Consumable replacement

• System inspection

• Firmware updates

Cleaning

Exterior Cleaning

Clean external surfaces to remove dust and residue.

1. Power off the printer.

2. Disconnect the power cable.

3. Wipe exterior surfaces using a soft, lint-free cloth.

4. Use water or a mild, non-abrasive detergent if required.

5. Allow surfaces to dry before reconnecting power.

Do not use abrasive materials or harsh chemicals.

Interior Cleaning

Internal cleaning removes debris that may affect print and encode performance.

1. Open the printer cover.

2. Remove installed ribbon and media.

3. Gently remove dust, debris, and residue from internal components.

4. Avoid contact with sensitive components, including the RFID antenna and print head.

5. Reinstall ribbon and media after cleaning.

Calibration

Media Calibration

Media calibration aligns label feeding and positioning.

Perform media calibration:

• After replacing labels or ribbon

• If feed alignment issues are observed

For calibration procedures, refer to Calibrating the SATO CL4NX.



Print Head and Media Alignment

Print head and media alignment affects print consistency.

1. Verify that labels and ribbon are seated in the media guides.

2. Verify that the RFID antenna assembly is fully latched.

3. Confirm that the print head is locked in position.

Adjust alignment if mispositioning is observed.



Replacing Consumables

Replacing the Thermal Ribbon

Replace the thermal ribbon when depleted or damaged.

1. Remove the depleted ribbon.

2. Install compatible replacement ribbon.

3. Verify correct ribbon orientation and tension.

For supported supplies, refer to the Label and Thermal Ribbon Ordering Guide.



Preventive Maintenance

System Inspection

Inspect the printer regularly for:

• Physical damage

• Loose components

• Abnormal operation

Report abnormal conditions to support@ramp.com.au.
